Surge Protection Device (SPD)

Is your electrical and electronic equipment shielded from lightning and transient surges? As per a study, around 65% of electronic equipment degradation is attributed to transient surges, indirect lightning, and faulty wiring. These factors contribute to premature aging, data loss, and sometimes complete equipment failure

ASHLOK’S lineup of Surge Protection Devices, when integrated into panels and distribution boards, guard against internally generated surges and the impact of indirect lightning strikes. This safeguards the durability of electrical and electronic appliances, shielding them from deterioration caused by surge-related consequences.

Class B Surge Protection Device (3+1)

  • Devices for AC Surge Protection
  • Meets Type 1 (T1), Class I, and Class B standards
  • SPD compliant with EN 61643-11 and IEC 61643-11
  • Voltage capability from 275 V to 600 V AC
  • Available in 1P, 1P+N, 2P, 2P+N, 3P, 3P+N, and 4P configurations
  • Equipped with Gas Discharge Tube (GDT)

Class C Surge Protection Device (3+1)

  • AC Surge Protection Devices as per EN 61643-11 and IEC 61643-11
  • Type 2 (T2), Class II, and Class C protection
  • Voltage tolerance from 275 V to 600 V AC
  • Designed with a plug-in module concept
  • Features a device status indicator and optional remote indication contact
  • Suitable for 1P, 1P+N, 2P, 2P+N, 3P, 3P+N, and 4P connections

Solar PV Surge Protection Device

  • Rapid self-protection via swift thermal response
  • Available with or without remote indication contact
  • Incorporates a plug-in module configuration
  • Offers IP 20 protection level
  • Designed for DC Surge Protection
  • Compliant with Type 2 (T2), Class II, and Class C standards)
  • Variants for Ucpv 600Vdc, 1000Vdc, and 1500Vdc
  • SPD designed as per EN 50539-11 and IEC 61643-31

Street Light Surge Protection Device

  • Includes built-in LED indicator for simplified maintenance and replacement identification
  • Thermal protection feature
  • Maximum discharge current of 20kA
  • Offers robust line-to-ground/earth resistance
  • Rated IP 66 for resistance against dust and water
  • Meets IEC 61643-11 standards
  • Suitable for use in luminaires with Class I or Class II insulation

DCDB

  • Polymer housing with UV resistance | IP Class - 54
  • Non-combustible polymer construction
  • streamlined cable management, simple and evident
  • Withstands varied weather conditions and ensures extended life
  • Available for 500V and 1000V DC systems
  • I/O configurations range from 1 in 1 out to 12 in 12 out
  • Constructed from Poly-Carbonate material
  • Installation and upkeep made convenient
